Solenoid Inductance Calculation
These calculations can be used separately. For pure
inductance fill in the second table only, For inductance from a length diameter
and wire size fill in the top table, the bottom one will fill its self in from
the data. There is an inches-mm or mm-inches conversion below for easy
referance.
These calculators can be used for
either primary or secondary single layer helical coils.
Solenoid Wiring
| Solenoid coil length | mm | |
| Wound with | mm diameter wire ( % stacking factor) | |
| on a | mm diameter former | |
| gives a total of | Turns | |
| using | meters of wire |
Solenoid Inductance
| Solenoid Coil length | mm | |
| wound with | Turns | |
| With a Coil diameter of | mm | |
| Then the inductance of the solenoid is | mH. | |
| and the self capacitance of the solenoid is | pF. | |
| Self Resonant At | Khz |
